油煙凈化器工作原理及特點

發布人：http://hwzxw.net   發布時間：2018-05-03 15:15:13

    油煙凈化器工作原理如下：
    The working principle of the oil fume purifier is as follows:
    可使油煙由風機吸入油煙凈化器，其中部分較大的油霧滴、油污顆粒在均流板上由于機械碰撞、阻留而被捕集。當氣流進入高壓靜電場時，在高壓電場的作用下，油煙氣體電離，油霧荷電，大部分得以降解炭化；少部分微小油粒在吸附電場的電場力及氣流作用下向電場的正負極板運動被收集在極板上并在自身重力的作用下流到集油盤，經排油通道排出，余下的微米級油霧被電場降解成二氧化碳和水，較終排出潔凈空氣；同時在高壓發生器的作用下，電場內空氣產生臭氧，除去了煙氣中大部分的氣味。
    The oil fume can be inhaled by the fan, and some of the larger oil droplets and oily particles are arrested on the current board due to mechanical collision and retention. When the air flow enters the high voltage electrostatic field, under the action of the high voltage electric field, the oil smoke gas ionized and the oil mist charged, most of which could degrade the carbonization. The small fraction of the tiny oil particles were collected on the plate with the electric field force and the air flow under the action of the electric field. Through the discharge channel, the remaining micrometer oil mist is degraded into carbon dioxide and water by the electric field, and the clean air is discharged. At the same time, under the action of the high pressure generator, the air in the electric field produces ozone, which removes most of the odor in the flue gas.

    特點：
    Characteristic：
    1.油煙凈化器的電場使用圓筒蜂窩式結構，使靜電場能均勻地達到較大的平均電場強度，極大的增加了電場凈化面積，使電場與油煙粒子結合作用的時間更長，從而決定了設備具有極高的除油煙效率；
    the electric field of the oil and smoke purifier uses a cylindrical honeycomb structure, which makes the electrostatic field achieve the maximum average electric field strength, greatly increases the area of the electric field purification, and makes the electric field combined with the oil smoke longer longer, thus determining the high efficiency of the removal of the fume from the equipment.
    2.電場模塊化設計，可按風量大小拼裝成型，蜂窩式的電場鋼性好、便于拆裝、不會變形，清洗維護方便等特點；
    the modular design of electric field can be assembled according to the size of the air volume. The honeycomb electric field is characterized by good steel property, easy disassembly and assembly, no deformation, easy cleaning and maintenance, etc.
    3.設備運行時噪音小，阻力小，運行成本很低；
    the equipment has low noise, low resistance and low running cost.
    4.油煙凈化器系數高，更好地高壓連接設計，開門時電場會自動斷電；
    the fume purifier has high safety factor and better design of high voltage connection. When the door is opened, the electric field will automatically cut off.
    5.電源在保證凈化器較好凈化效果的同時，還具有自動的過載、過壓、斷路、開路保護，使用更、更放心進出風口可隨意互換，方便現場安裝需要；
    power supply, while ensuring the best purification effect of the purifier, also has automatic overload, overvoltage, circuit breakage, open circuit protection, the use of more safe, more assured import and export of the vent can be exchanged at will, convenient for site installation needs;
    6.油煙凈化器凈化效率高，經檢測，油煙凈化率高于90%，并能去除大部分氣味。
    the purification efficiency of fume purifier is high. After testing, the oil fume purification rate is higher than 90%, and most of the odor can be removed.
