山東通風管道?裝置過程要小心避免哪些問題？

發布人：http://hwzxw.net   發布時間：2020-04-14 13:29:46

　　一般通風管道在安裝通風管道時，有一定的方法，如果不按照標準進行安裝，將會影響管道在后期的正常使用，下面，我們將簡要了解這方面的內容。

　　In general, there are certain methods for the installation of ventilation pipes. If the pipes are not installed according to the standards, it will affect the normal use of the pipes in the later period. Next, we will briefly understand this aspect.

　　1. 管道組裝:管道較短時，可一次在地面組裝;管道較長時，可根據現場安裝情況，在地面分段安裝。在安裝過程中，應盡量調整管道的水平度，以避免管道變形或上下波動，從左向右擺動。當管道各部分不超過10m時，墊片應平整，法蘭螺栓應均勻緊固，螺母蓋應向同一方向。

　　1. Pipeline assembly: when the pipeline is short, it can be assembled on the ground at one time; when the pipeline is long, it can be installed on the ground in sections according to the site installation situation. During the installation, the levelness of the pipeline shall be adjusted as much as possible to avoid the deformation or fluctuation of the pipeline, and the pipeline shall swing from left to right. When each part of the pipeline does not exceed 10m, the gasket shall be flat, the flange bolts shall be tightened evenly, and the nut cover shall be in the same direction.

　　2. 管道就位前，應檢查各支座的水平度和標高，并檢查支座的牢固度。兩種方法，直接和吊索，可用于空氣管道的地方。風管截面小，且位置低，可采用人工放置方法，只需設置簡單的腳手架即可。當風道斷面較大、管道斷面較長時，可采用滑輪、倒鏈、大繩等吊裝方式。

　　2. Before the pipeline is in place, the levelness and elevation of each support shall be checked, and the firmness of the support shall be checked. Two methods, direct and sling, can be used where air ducts are located. The section of the air duct is small and the position is low, so the manual placement method can be adopted, and only a simple scaffold can be set. When the cross-section of the air duct is large and the cross-section of the pipeline is long, pulley, chain block, rope and other hoisting methods can be used.

　　為了方便管道的位置，一般采用管道掛在支架上，然后將其吊在管道支架上的方法。腳手架應沿長度方向設置風道,高度和位置應該適合施工操作,起重序列應該一干燥管的支持后,垂直管、起重、吊點應公司,兩個吊點應統一的力量。垂直風道可安裝手動和大繩支撐。調節風道，保證垂直度。

　　In order to facilitate the location of the pipeline, the method of hanging the pipeline on the bracket and then hanging it on the bracket is generally adopted. The scaffold shall be provided with air duct along the length direction, and the height and position shall be suitable for construction operation. The lifting sequence shall be supported by the first drying pipe. The vertical pipe, lifting and lifting points shall be provided by the company, and the two lifting points shall have the same force. The vertical air duct can be installed with manual and rope support. Adjust air duct to ensure verticality.

　　3.通風管道在支架上的位置應調整到正確的位置，然后根據地圖集的要求進行固定。

　　3. The position of the ventilation pipe on the support shall be adjusted to the correct position, and then fixed according to the requirements of the atlas.

　　這是通風管道安裝的基本過程。另外，在安裝過程中應注意以下幾點:

　　This is the basic process of ventilation pipe installation. In addition, pay attention to the following points during installation:

1. 風道與風機連接時，應在空氣的進出口處加軟接頭。軟接頭的截面尺寸應與風機進出口截面尺寸一致。軟管接頭一般可采用帆布、人造革等材料，軟管長度不應小于200，松緊度應適當，柔性軟管可緩沖風扇的振動。

2.


　　1. When the air duct is connected with the fan, a soft joint shall be added at the air inlet and outlet. The section size of soft joint shall be consistent with that of fan inlet and outlet. Generally, the hose joint can be made of canvas, artificial leather and other materials. The hose length should not be less than 200. The tightness should be appropriate. The flexible hose can cushion the vibration of the fan.

　　2. 通風管道與除塵設備、加熱設備連接前，設備安裝完畢后，應按實際測繪圖紙預制安裝。

　　2. Before connecting the ventilation pipe with the dedusting equipment and heating equipment, and after the equipment is installed, it shall be prefabricated and installed according to the actual mapping drawings.

　　3.管道安裝時，應在管道預制當天打開進出口。如果安裝后需要打開管道上的出口，則連接應緊密。

　　3. During pipeline installation, the inlet and outlet shall be opened on the day of pipeline prefabrication. If the outlet on the pipe needs to be opened after installation, the connection shall be tight.

　　4. 輸送凝結水或含濕量較大的氣體時，水平管線應設置坡度，排水管道應在更低點連接。安裝時管道底部不應出現縱向接縫，底部接縫應密封。

　　4. When transporting condensate or gas with large moisture content, the horizontal pipeline shall be provided with gradient, and the drainage pipeline shall be connected at the lowest point. During installation, there shall be no longitudinal joint at the bottom of the pipe, and the bottom joint shall be sealed.

　　5. 輸送易燃易爆氣體的鋼管應在連接法蘭處安裝跳線連接，并與靜電地網連接。

　　5. The steel pipe conveying inflammable and explosive gas shall be connected with jumper wire at the connecting flange, and connected with electrostatic grounding grid.

　　6. 雙吊桿支架就位后，橫臂應伸直，吊桿不得更換，雙吊桿受力應均勻。

　　6. After the double suspender bracket is in place, the cross arm shall be extended straight, the suspender shall not be replaced, and the stress of the double suspender shall be even.

　　7. 當水平風道高度大于2米時，安裝人員應、配合。腳手架或可移動支架上的木板應固定，木板的寬度應符合標準，腳手架上的安裝人員應背著背包，避免東西或電鉆等掉落傷害。

　　7. When the height of horizontal air duct is more than 2m, the installation personnel shall be safe and cooperative. The board on the scaffold or movable support shall be fixed, and the width of the Board shall meet the standard. The installation personnel on the scaffold shall carry a backpack to avoid falling things or electric drills.

　　以上就是對山東通風管道裝置過程的注意事項的詳細介紹，想要了解更多請點擊官網http://hwzxw.net

　　The above is a detailed introduction of the precautions for the process of ventilation duct installation in Shandong Province. For more information, please click http://hwzxw.net
