通風管道加工的系統布局需要注意什么!
發布人:http://hwzxw.net 發布時間:2023-03-30 11:47:55
一、系統網的布局形式
1、 Layout of system network
為方便管網的管理和運行調節,管網系統不宜過大,同一系統有多個分支管時,應將這些分支管分級控制,且同一系統的吸氣點不宜過多,一定要注意各支管的壓力平衡。常用的管網布局方式有干管配管、個別配管、環狀配管3種。
In order to facilitate the management and operation adjustment of the pipe network, the pipe network system should not be too large. When there are multiple branch pipes in the same system, these branch pipes should be controlled hierarchically, and the suction points of the same system should not be too many. It is important to pay attention to the pressure balance of each branch pipe. There are three commonly used pipe network layout methods: main piping, individual piping, and annular piping.
二、布局的原則
2、 Principles of layout
1、通風管道安裝系統的鋪設原則
1. Laying principles of ventilation pipe installation system
管道鋪設分明裝、暗裝,一般采用明裝。因?yàn)槊餮b以便于檢修,在無法采用明裝時考慮暗裝方式,管道盡可能的集中成列,盡量沿墻或柱子平行鋪設,若管徑大或保溫應布局在靠墻側。一般兩根管道平行布局時,間距不小于100~200mm。
The pipeline shall be laid in a clear and concealed manner, and generally installed in an open manner. Because open installation is convenient for maintenance, when it is not possible to use open installation, consider concealed installation. The pipes should be concentrated in rows as much as possible, and laid parallel to the wall or column as much as possible. If the pipe diameter is large or the insulation should be placed on the side against the wall. Generally, when two pipes are arranged in parallel, the spacing shall not be less than 100-200mm.
2、通風管道加工系統的連接原則
2. Connection principles for ventilation pipe processing systems
在以焊接為主要連接方式方法的管道中,應設置足夠數量的法蘭連接,在以螺紋為主的連接管道中應設置足夠的活接頭,以便宜于安裝、拆卸、檢修。
In pipelines where welding is the main connection method, a sufficient number of flange connections should be provided, and in threaded pipelines, sufficient unions should be provided to facilitate installation, disassembly, and maintenance.
3、通風管道加工系統的支撐原則管道不宜與閥件直接支撐在設備上,應單獨設置支架或吊架,管道的焊縫位置應在施工方便或受力較小的地方,焊縫不得位于支架處且距離不小于200mm。
3. Support principle for the ventilation pipe processing system: The pipe should not be directly supported on the equipment with the valve. Instead, a separate bracket or hanger should be provided. The welding seam of the pipe should be located at a place where construction is convenient or the stress is small. The welding seam should not be located at the bracket and the distance should not be less than 200mm.
4、不同含塵氣體性質不同,則凈化的分段處理應不同。
4. Different dust containing gases have different properties, so the segmented treatment of purification should be different.
當污染源多時可以集中在一個凈化系統中,也可分為幾個系統,但出現污染物混合會引起燃燒、爆炸危險、不同溫度和濕度的氣體,混合后出現管道內結露、粉塵或氣體性質不同,影響回收或凈化效率的。
When there are many sources of pollution, they can be concentrated in a purification system or divided into several systems. However, mixing of pollutants can cause combustion, explosion hazards, and gases with different temperatures and humidity. After mixing, condensation in the pipeline, dust, or gases with different properties may occur, affecting recovery or purification efficiency.
5、通風管道加工系統布局中要保證整體系統的漏損小,確保吸塵口的有足夠的風量。
5. In the layout of the ventilation pipe processing system, it is necessary to ensure that the leakage of the overall system is small and that there is sufficient air volume at the dust suction port.
6、通風管道加工系統布局要減小阻力。
6. The layout of the ventilation pipe processing system should reduce resistance.
